Mini T5 G5 UV-C 20W

Add to compare

Print PDF

Product tags

The Mini T5 G5 UV-C Sterilization Lamp 20W is a slim double-ended UV-C germicidal lamp designed for residential water and air disinfection. With almost constant UV output throughout its lifetime, this lamp ensures maximum security of disinfection and high system efficacy. It's the perfect choice for small diameter lamp in residential applications, offering effective disinfection without over-designing the purification system. Plus, it is an environmentally friendly option with low mercury content.

Accessories

Accessories for Mini T5 G5 UV-C 20W

More info

Cap-Base G5
Bulb T16
Main Application Disinfection
Useful Life 11000 h
Lamp Wattage 20 W
Lamp Wattage Technical 20 W
Lamp Voltage 45 V
Lamp Current 0.450 A
Mercury (Hg) Content 4.4 mg
UV-C Radiation 6 W
Reference Length A 398 (max) mm
Overall Length B 402.7 (min), 405.1 (max) mm
Overall Length C 412.2 (max) mm
Diameter D 16 (max) mm

Benefits
• Small diameter lamps for residential applications
• Security of effective disinfection over the useful lifetime of the lamp
• High system efficacy because it is not required to over-design the purification system to maintain effectiveness of disinfection
• Good environmental choice because of lowest amount of mercury

Features
• Short-wave UV radiation with a peak at 253.7 nm (UVC) for disinfection purposes
• Protective inside coating ensures almost constant UV output over the complete lifetime of the lamp
• Special lamp glass filters out the 185 nm ozone-forming radiation
• Warning sign on lamp indicates that the lamp radiates UVC

Applications
• Deactivation of bacteria, viruses and other micro-organisms
• Residential drinking water units
• Fish pond water units
• In-duct air treatment units
• Stand alone air purifiers
