880315 | Manufacturer: Vossloh Schwabe | EAN: 4050732880315 | MPN: 188665
ELXs 124.902 is a versatile electronic ballast designed for compact fluorescent lamps, T5 and T8 lamps. With its heat-resistant polyamide casing and RFI-suppression, it ensures reliable performance in both protection class I and II luminaires. This ballast operates on a wide range of voltages (198-264V) and features push-in terminals for easy installation. Suitable for lighting systems with high switching frequency, it offers EOL shut down approved acc. to EN 61347 Test 2. Experience efficient illumination with ELXs 124.902!
Vossloh Schwabe ELXs 124 902 1x14 24W TC T5 T8 R5 electronic ballasts for Ballast. Illuminate your space with the ELXs 124.902 electronic ballast for T5, T8, and R5 lamps. Efficiently power up to 14 lamps this 24W TC-F L ballast.
Electronic built-in ballast
Casing: heat-resistant polyamide
Power factor: approx. 0.6 (depending on the lamp output)
DC voltage operation: 198 - 264 V
Push-in terminals with push-button: 0.5 - 1.5 mm²
RFI-suppressed
For luminaires of protection class I and II
Degree of protection: IP20
Fixing slots for screws M4
For lighting systems with high switching frequency (> 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-F/-L, T5 / T8, T-R5
Output [W]: 18, 24 for compact fluorescent lamps TC-F/-L (2G10/2G11)
Output [W]: 22 for compact fluorescent lamps T-R5 (2GX13)
Output [W]: 14, 15, 18 for T8 lamps (G13)
Output [W]: 24 for T5 lamps (G5)
Lamp number: 1
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –15 to 55
| Explanation Dimmable | no |
| Explanation Voltage - (V) | 220 |
| Explanation Protection mark - (IPXX) | 20 |
| Explanation Factory packed - (pieces) | 10 |
