Fluorescent lamps
Osram L 18W 840 G13
517797 | Manufacturer: Osram | EAN: 4050300517797 | MPN: L-18-840-ECO
More info
LUMILUX fluorescent lamps offer a sophisticated and economical lighting solution. With good to outstanding and uniform color reproduction, the lamps can meet even the toughest demands in the professional lighting sector.
Nominal wattage 18W
Rated lamp efficacy (standard condition) 75 lm/W
Rated wattage 18W
Energy consumption 23 kWh/1000h
Color rendering index Ra≥80
Rated luminous flux 1350 lm
Luminous flux at 25 °C 1350 lm
Light color 840
Color temperature 4000K
Nominal luminous flux 1350 lm
Light color as per EN 12464-1 LUMILUX Cool White
Rated LLMF at 2000h 0.95
Color coordinates chromaticity diagram 0.38/0.38
Tube diameter 26 mm
Length 590 mm
Length with base excl. base pins/connection 590 mm
Diameter 26 mm
Maximum diameter 26 mm
Lamp mercury content 2.5 mg
Rated ambient temp.w.max.luminous flux 25 °C
Service life 18000h
Lifespan 20000h
Rated lamp survival factor at 2000h 0.99
Rated lamp survival factor at 4000h 0.99
Operation mode LLMF/LSF 50Hz
Base (standard designation) G13
Appropriate disposal acc. to WEEE Yes
Dimmable Yes
Suitable for indoor Yes
Energy efficiency class A
Benefits
- Proven lamp technology
- Good economy thanks to high efficiency
- Available in many different light colors (2700…8000K) for various applications
Applications
- Public buildings
- Office lighting
- Industry
- Shops
- Supermarkets and department stores
- Street lighting
- Outdoor applications only in suitable luminaires
Features
- Very good lumen maintenance: 90% throughout the service lifetime of the lamp
- Good color rendering group: 1B (Ra: 80…89)
- Dimmable
- Top-quality three-band phosphor: LUMILUX
| It needs ballast | Yes |
| Dimmable | YES, with DIMM ECG |
| Energy Efficiency Class | A |
| Base/Sockel | G13 |
| Wattage - Watt (W) | 18 |
| Luminous flux - Lumen (lm) | 1350 |
| Luminous Efficacy Lamp - (lm / W) | 75 |
| Light color temperature - Kelvin (K) | 4000 |
| Light color code | 840 |
| Color rendering index - CRI | 83 |
| Energy consumption - (kWh / 1000h) | 18 |
| Lifetime - hours (h) | 20000 |
| Factory Box - pieces (pcs) | 25 |
