Fluorescent lamps
Osram L 36W 840 G13
517872 | Manufacturer: Osram | EAN: 4050300517872 | MPN: L-36-840-ECO
More info
LUMILUX fluorescent lamps offer a sophisticated and economical lighting solution. With good to outstanding and uniform color reproduction, the lamps can meet even the toughest demands in the professional lighting sector.
Nominal wattage 36 W
Rated lamp efficacy (standard condition) 93 lm/W
Rated wattage 36 W
Energy consumption 43 kWh/1000 h
Color rendering index Ra≥80
Rated luminous flux 3350 lm
Luminous flux at 25 °C 3350 lm
Light color 840
Color temperature 4000 K
Nominal luminous flux 3350 lm
Light color as per EN 12464-1 LUMILUX Cool White
Rated LLMF at 2000 h 0.95
Color coordinates chromaticity diagram 0.38/0.38
Tube diameter 26 mm
Length 1200 mm
Length with base excl. base pins/connection 1200 mm
Diameter 26 mm
Maximum diameter 26 mm
Lamp mercury content 2.5 mg
Rated ambient temp.w.max.luminous flux 25 °C
Service life 18000 h
Lifespan 20000 h
Rated lamp survival factor at 2000 h 0.99
Rated lamp survival factor at 4000 h 0.99
Operation mode LLMF/LSF 50 Hz
Base (standard designation) G13
Appropriate disposal acc. to WEEE Yes
Dimmable Yes
Suitable for indoor Yes
Energy efficiency class A
Benefits
• Proven lamp technology
• Good economy thanks to high efficiency
• Available in many different light colors (2700…8000 K) for various applications
Applications
• Public buildings
• Office lighting
• Industry
• Shops
• Supermarkets and department stores
• Street lighting
• Outdoor applications only in suitable luminaires
Features
• Very good lumen maintenance: 90% throughout the service lifetime of the lamp
• Good color rendering group: 1B (Ra: 80…89)
• Dimmable
• Top-quality three-band phosphor: LUMILUX
| It needs ballast | Yes |
| Dimmable | YES, with DIMM ECG |
| Energy Efficiency Class | A |
| Base/Sockel | G13 |
| Wattage - Watt (W) | 36 |
| Luminous flux - Lumen (lm) | 3350 |
| Luminous Efficacy Lamp - (lm / W) | 93 |
| Light color temperature - Kelvin (K) | 4000 |
| Light color code | 840 |
| Color rendering index - CRI | 83 |
| Energy consumption - (kWh / 1000h) | 36 |
| Lifetime - hours (h) | 20000 |
| Factory Box - pieces (pcs) | 25 |
