T5 High Efficiency fluorescent lamps

Osram T5 FH 28W 830 he High Efficient G5

591483 | Manufacturer: Osram | EAN: 4050300591483 | MPN: FH-28-830

Extremely efficient, reliable and a long service life – LUMILUX fluorescent lamps from Osram offer a sophisticated and economical lighting solution. With good to outstanding and uniform color reproduction, the lamps can meet even the toughest demands in the professional lighting sector.


$ 3.87

Price for 1 piece, excluding shipping costs!
Condition: New product
Factory Box - pieces (pcs): 20

-+

More info

Nominal voltage 220V
Nominal wattage 27.90W
Rated lamp efficacy (HF data 25 °C) 93 lm/W
Rated wattage 27.90W

Color rendering index Ra≥80
Rated luminous flux 2600 lm
Luminous flux at 25 °C 2600 lm
Luminous flux at 35 °C 2900 lm
Light color 830
Color temperature 3000K
Nominal luminous flux 2600 lm
Light color as per EN 12464-1 LUMILUX Warm White
Rated LLMF at 2000h 0.95
Rated LLMF at 4000h 0.92

Tube diameter 16 mm
Length 1149 mm
Length with base excl. base pins/connection 1149 mm
Diameter 16 mm
Maximum diameter 16 mm

Rated ambient temp.w.max.luminous flux 35 °C

Service life 19000h
Lifespan 24000h
Operation mode LLMF/LSF HF
Rated lamp life time 24000h
Nominal lamp life time 24000h

Base (standard designation) G5
Lamp mercury content 2.5 mg
Appropriate disposal acc. to WEEE Yes
Footnote only for product Suitable for ECG operation only/Lamp designed for internal luminaire temperatures of 30…40 °C; optimum luminous flux achieved at 35 °C

Dimmable Yes
Suitable for indoor Yes

Energy efficiency class A+
Energy consumption 31 kWh/1000h

Product benefits
-Good economy and efficiency
-Up to 20% more economical than LUMILUX T8
-Up to 50% smaller volume than comparable T8 lamps
-Natural colors

Areas of application
-Public buildings
-Offices
-Shops
-Supermarkets and department stores
-Industry

Data sheet

Data sheet: T5 High Efficiency fluorescent lamps T5 FH 28W 830 he High Efficient G5

It needs ballastYes
DimmableYES, with DIMM ECG
Energy Efficiency ClassA+
Base/SockelG5
Voltage - Volt (V)220
Wattage - Watt (W)28
Luminous flux - Lumen (lm)2600
Luminous Efficacy Lamp - (lm / W)93
Light color temperature - Kelvin (K)3000
Light color code830
Color rendering index - CRI83
Energy consumption - (kWh / 1000h)28
Lifetime - hours (h)24000
Factory Box - pieces (pcs)20
