Predstikalne naprave, elektronske HID

Osram PTI 35/220 240 S

073112 | Proizvajalec: Osram | EAN: 4008321073112 | MPN: PTI-35-S

POWERTRONIC INTELLIGENT PTi S elektronska predstikalna naprava za HID sijalke, namestitev v svetilke.


40,72 €z DDV
33,37 €brez DDV

Cena za 1 kos.
Stanje: Nov izdelek
Tovarniško pakiranje - kosov (kos): 20

Z nakupom tega izdelka lahko zberete do 6 točk zvestobe. Vaša košarica bo dobila skupaj 6 točke, ki se jih lahko zamenja za kupon v vrednosti 0,60 €.

-+

Podrobnosti

Podrobnosti

Lamp wattage 39W
Line current 0.19A
Ignition voltage 4.5 kVp
Operating frequency 0200…0.240 kHz
System wattage 43W
ECG efficiency 91%
Input voltage 220…240V
Voltage range 198…264V
Mains frequency 50…60Hz
Power factor λ 0.95
Inrush current 30A
Max. no. of ECGs on circuit breaker 10A 15
Max. no. of ECGs on circuit breaker 16A 26
Max. no. of ECGs on 16A MCB with EBN-OS 65
Protective conductor current 0.25 mA
U-OUT 250V
Max. working voltage between LH and LL 250V
Max. working voltage betw. LL/LH andamp; earth 250V
Max. capacitance of wire ECG/lamp 120 pF

Length 110 mm
Width 75 mm
Height 30 mm
Mounting hole spacing, length 99 mm
Mounting hole spacing, width 64 mm
Cable cross-section, input side 0.5…2.5mm²
Cable cross-section, output side 0.5…2.5mm²
Wire preparation length, input side 10…11 mm
Wire preparation length, output side 10…11 mm

Casing material Metal

Ambient temperature range -25…+65 °C
Maximum temperature at tc test point 85 °C

ECG lifetime 50000h

Design / version Built-in unit
System guarantee level 3c

Maximum wiring length ECG/lamp 1.5m
Overheating protection Power reduction and switch off at T > 85 °C at the tc point
Overvoltage protection at 275…300V 48 h
Overvoltage protection at 300…320V 2 h
Overvoltage protection at 320…350V 5 min
ECG reset time > 0.5s
Dimmable No
Restriction on ignition time 20 min
Suitable for fixtures with prot. class I

Approval marks – approval ENEC 10 / VDE / VDE-EMC / GOST / C-Tick
Type of protection IP20
EEI – Energy Label A2
Standards acc. to EN 61347-2-12/acc. to EN 55015/acc. to EN 61000-3-2/acc. to EN 61547

Product benefits
-Long reliable life at maximum permitted temperatures
-Compact dimensions and low weight for small luminaire designs
-Excellent thermal behavior for very high limit temperatures tc and ta
-Automatic safety shutdown of lamps in the event of a defect or at end of life (EoL)

Areas of application
-Shop lighting
-Health and fitness areas
-Effect and accent lighting

Možnost zatemnitveDa
Napetost - Volt (V)220
Moč - Watt (W)35
Poraba energije - (kWh / 1000h)35
Mednarodna oznaka zaščite - (IPXX)IP20
Življenska doba - ure (h)50000
Tovarniško pakiranje - kosov (kos)20
