215301 | Manufacturer: Philips | EAN: 8718291215301 | MPN: 928482400092
RX7s MHN TD 70W 730 lamp illuminate your space
More info
Philips RX7s MHN TD 70W 730 lamp illuminate your space. Illuminate your space with the RX7s Lamp MHN TD 70W 730, a standout in our Metal Halide Lamps category. Experience superior brightness and energy efficiency today
Cap-Base RX7s
Cap-Base Information na
Bulb TD
Bulb Finish Clear
Operating Position p45 [Parallel ±45D or Horizontal(HOR)]
Life to 5% failures 5000 h
Life to 20% failures 7000 h
Life to 50% failures 9000 h
Color Code 730 [CCT of 3000 K]
Color Rendering Index 70 Ra8
Color Designation Warm White
Luminous Flux Lamp EM 6000 lm
Luminous Efficacy Lamp EM 80 lm/W
Lumen Maintenance 2000 h 65%
Lumen Maintenance 5000 h 60%
Lumen Maintenance 10000 h 55%
Luminance Average EM 1600 cd/cm²
Chromaticity Coordinate X 434 -
Chromaticity Coordinate Y 400 -
Lamp Voltage 90 V
Lamp Current EM 0.98 A
Ignition Peak Voltage 1800 (min) V
Dimmable No
Energy Efficiency Label (EEL) A+
Mercury (Hg) Content 13.4 mg
Energy consumption kWh/1000 h 77 kWh
Pinch Temperature 280 (max) °C
Bulb Temperature 500 (max) °C
Insertion Length B 114.2 (max) mm
Overall Length C 117.6 (max) mm
Diameter D 19.5 (max) mm
Light Center Length L 57 mm
Arc Length O 7.7 mm
Light Center Length L [inch] 2.24 in
Overall Length C [inch] 4.63 (max) in
Diameter D [inch] 0.75 in
Benefits
• All types are UV-Block for reduced health and fading risks
Features
• Quartz discharge tube containing high-pressure mercury and a mixture of dysprosium, holmium and thulium halides (4200 K) or tin iodide (3000 K), with sodium and thallium added for color correction and arc stabilization
• Double-ended lamps housed in a tubular clear UV-Block quartz evacuated outer envelope
• Restricted burning position
Applications
• Indoors - accent lighting, general lighting in downlighters, e.g. in shops and malls
• Downlighters, uplighters and wall-washers, e.g. in shops and malls
• Outdoors - floodlighting monuments, facades and billboards
| Explanation It needs ballast | yes |
| Explanation Energy efficiency class | A+ |
| Explanation Lamp holder, lamp socket | RX7s |
| Explanation Wattage - (W) | 70 |
| Explanation Luminous flux - (lm) | 3800 |
| Explanation Luminous efficacy - (lm / W) | 86 |
| Explanation Color temperature - (K) | 3000 |
| Explanation Light color code | 730 |
| Explanation Color rendering - (CRI) | 70 |
| Explanation Energy consumption - (kWh / 1000h) | 70 |
| Explanation Lifetime - (h) | 9000 |
| Explanation Factory packed - (pieces) | 12 |
| Bulb type | discharge lamps |
| Technology | HID |
