197825 | Manufacturer: Philips | EAN: 8711500197825 | MPN: 928082205125
RX7s MasterColour CDM-TD 70W 830
The RX7s Metal Halide Lamp MasterColour CDM-TD 70W 830 is a single-ended, compact, and high-efficiency discharge lamp. With its stable color over time and sparkling light, it offers a beautiful sparkle and reliable life. This lamp has a long lifespan compared to other types of lamp and produces low heat output for enhanced comfort. It also provides superior color quality and can be retrofitted in double-ended luminaires for reduced operating costs. Perfect for shops, offices, public buildings, and decorative outdoor lighting applications.
More info
Cap-Base RX7s
Bulb T22 [T 22 mm]
Bulb Finish Clear
Operating Position p45 [Parallel ±45D or Horizontal(HOR)]
Life to 50% failures 16000 h
Color Code 830 [CCT of 3000 K]
Color Rendering Index 82 Ra8
Color Designation Warm White
Color Temperature 3000 K
Color Temperature Technical 2990K
Luminous Flux Lamp EM 6000 lm
Luminous Efficacy Lamp EM 85 lm/W
Luminous Efficacy System EL 78 lm/W
Lumen Maintenance 2000 h 87%
Chromaticity Coordinate X 0.443 -
Chromaticity Coordinate Y 0.401 -
Lamp Wattage 70 W
Lamp Voltage 92 V
Lamp Current EM 0.95 A
Ignition Time 30 (max) s
Run-up time 90% 3 (max) min
Re-ignition Time [min] 15 (max) min
Dimmable No
Energy Efficiency Label (EEL) A+
Mercury (Hg) Content 3.7 mg
Energy consumption kWh/1000 h 78 kWh
PET (NIOSH) 41 h.klx
Damage Factor D/fc 0.23 -
Pinch Temperature 280 (max) °C
Bulb Temperature 500 (max) °C
Reference Length A 114.2 mm
Insertion Length B 117.6 (max) mm
Overall Length C 119.63 (max) mm
Diameter D 22 (max) mm
Light Center Length L 57.1 mm
Arc Length O 8 mm
Light Center Length L [inch] 2.25 in
Overall Length C [inch] 4.6875 (max) in
Diameter D [inch] 0.75 in
Beautiful sparkle, reliable life
• Stable color impression over lifetime
• High lamp efficacy results in low operating costs and low heat generation. Provides better operating costs and improved light quality versus standard quartz metal halide (MHN-TD)
• Long lamp life compared with incandescent, halogen and quartz metal halide (MHN-TD) lamps
• Relatively low heat output enhances comfort for shoppers and staff
• All types are UV-Block for reduced fading risks
Features
• Crisp white light
• Superior color quality
• Retrofit in double-ended luminairs for quartz metal halide lamps (MHN-TD), thereby allowing to reduce operating costs and improve color quality
• Burning position horizontal ±45°
Applications
• Shops and shop windows, offices and public buildings
• Decorative outdoor: floodlighting of facades, statues and monuments
