384135 | Manufacturer: Philips | EAN: 8718699384135 | MPN: 912401483118
Lamp family code Led45S [ Led Module, system flux 4500 lm]
Light source color 840 neutral white
Light source replaceable No
Number of gear units 1 unit
Driver/power unit/transformer Power supply unit
Driver included Yes
Optical cover/lens type Glass flat frosted
Luminaire light beam spread 100°
Connection Flying leads/wires
Cable Cable 0.5mwith cable connector 3-pole
Protection class IEC Safety class I
CE mark CE mark
Warranty period 3 years
Optic type outdoor Very wide beam angle 100°
Constant light output No
Number of products on MCB of 16 A type B 40
RoHS mark RoHS mark
Light source engine type Led
Input Voltage 220 - 240 V
Input Frequency 50 - 60 Hz
Inrush current 0.64 A
Inrush time 1 ms
Power Factor (Min) 0.9
Dimmable No
Housing Material Polycarbonate
Optic material Glass
Optical cover/lens material Glass
Fixation material Stainless steel
Mounting device Mounting bracket adjustable
Optical cover/lens shape Flat
Optical cover/lens finish Frosted
Overall length 207 mm
Overall width 55 mm
Overall height 185 mm
Effective projected area 0.039 m²
Width 207 mm
Ingress protection code IP65 [ Dust penetration-protected, jet-proof]
Mech. impact protection code IK07 [ 2 J reinforced]
Surge Protection (Common/Differential) 2/2 kV
Initial luminous flux (system flux) 4500 lm
Luminous flux tolerance ±10%
Initial Led luminaire efficacy 90 lm/W
Init. Corr. Color Temperature 4000 K
Init. Color Rendering Index >80
Initial input power 50 W
Power consumption tolerance ±10%
Control gear failure rate at median useful life 35000 h 7.5%
Lumen maintenance at median useful life 50000 hL70
Ambient temperature range -25 to +40 °C
Performance ambient temperature Tq 25 °C
Benefits
• Philips quality and reliability
• Fast payback: energy savings >80% (halogen lamps)
• Quick installation without opening the floodlight
• Philips high-quality finish, robust and fully reliable
Features
• System flux: 900 lm (10W); 2500 lm (27 W); 4500 lm (50W) versions with Neutral White, CRI 80 and a high efficiency of 90 lm/W
• Extra flat IP65 design of floodlights, supplied with cable, and that can be mounted Standing-up or hanging-down
• Motion detector versions
• Long lifetime of 35000 hours (Ta 25 °C)
• Prismatic glass for comfortable light
• CE, CB, ROHS compliant
Applications
• Building facades, retailing stores
• Gardens, underpasses
• Billboards
