186072 | Manufacturer: Vossloh Schwabe | EAN: 4014364282282 | MPN: 186072

LiteLine EST 70 transformers premium for electronics


Product is out of production!

Upgrade your lighting system with the LiteLine EST 70 Electronic Transformer. This versatile transformer is designed for low-voltage halogen incandescent lamps, providing a safe and efficient power conversion. With a capacity range of 20-70W and voltage compatibility of 220-240V, it offers reliable performance in any setting. The heat-resistant polyamide casing ensures durability, while features like protection against no load operation and short-circuiting guarantee safety. Suitable for installation in furniture or on combustible surfaces, this transformer is a must-have for enhancing your lighting experience.

    More info

    More info

    Vossloh Schwabe LiteLine EST 70 transformers premium for electronics Transformer. Experience the power and reliability of LiteLine EST 70, a standout in our Electronic Transformers category. Ideal for your high-performance needs.

    Type: EST 70/12.380
    Capacity Range: 20 - 70 W
    Voltage: 220 - 240 V
    Nominal Current: 0.30-0.31 A
    Ambient temperature: –20…45 °C
    Casing temperature: max. 70 °C
    Electronic safety converters for low-voltage halogen incandescent lamps 12 V.
    Casing: heat-resistant polyamide
    Mains frequency: 50 - 60 Hz
    Protection against no load operation
    Protection against short-circuit: electronic switch-off with automatic restart
    Electronically controlled overload and temperature protection
    Suitable for installation in furniture and on combustible surfaces
    Power factor: > 0.95
    Efficiency: > 94%
    Dimming: optional with phase-cutting leading-edge or phase-cutting trailing-edge dimmer (EST 35/12.650: only phase-cutting trailing-edge dimmer)
    Screw terminals: 2.5 mm² (EST 60/12.635 primary: 4 mm²)
    Quantity of screw terminals:
    1 × 2-poles primary
    1 × 2-poles secondary
    With integrated cord grip
    Protection class II
    SELV-equivalent
    Degree of protection: IP20
    RFI-suppressed

    Explanation Dimmable yes
    Explanation Voltage - (V) 220
    Explanation Wattage - (W) 70
    Explanation Protection mark - (IPXX) 20
    Explanation Factory packed - (pieces) 10
