188921 | Manufacturer: Vossloh Schwabe | EAN: 4050732128233 | MPN: 188921
ELXc 135 220 1x14 35W T5 electronic ballasts for
Product is out of production!
Product tags Product tags
ELXc 135.220 1x14 35W T5: High-performance electronic ballast for T5 fluorescent lamps. Ideal for lighting systems with frequent switching and emergency lighting applications. Features automatic restart after lamp replacement and EOL shutdown approved according to EN 61347 Test 1. Suitable for use in luminaires of protection class I, with a wide operating voltage range of 176-264V and ignition voltage range of 198-264V. Reliable, energy-efficient, and compatible with T5 HE lamps (G5 base).
More info
Vossloh Schwabe ELXc 135 220 1x14 35W T5 electronic ballasts for Ballast. Illuminate your space with the ELXc 135.220 electronic ballast for T5 lamps. Efficiently power lighting needs this high-quality product.
ELXc - Warm Start new T5 EffectLine
Electronic built-in ballasts
DC voltage: for operation: 176 - 264 V
for ignition: 198 - 264 V
Casing: metal
Push-in terminals with lever opener: 0.5 - 1.5 mm²
For luminaires of protection class I
Degree of protection: IP20
For lighting systems with high switching frequency (> 5/day)
Automatic restart after lamp has been changed
Suitable for use in luminaires for emergency lighting systems acc. to VDE 0108
EOL shut down approved acc. to EN 61347 Test 1
Lamp type: T5 HE
Casing: M6 and M10
Output [W]: 1 × 14, 1 × 21, 1 × 28, 1 × 35 for T5 lamps (G5)
Lamp number: 1
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C): –15 to 55 °C
| Explanation Dimmable | no |
| Explanation Voltage - (V) | 220 |
| Explanation Wattage - (W) | 14,21,28,35 |
| Explanation Protection mark - (IPXX) | 20 |
| Explanation Factory packed - (pieces) | 10 |
