LED driver LPF 60D 24 24V 60W IP67 brighten your home with mean well

This LED driver LPF 60D 24 24V 60W IP67 is the perfect choice for your Led lighting and moving sign applications. It features universal AC input, active PFC function, 3 in 1 dimming function, cooling by free air convection, fully isolated plastic case with IP67 rating and 5 years warranty. UL8750/CSA C22.2 No. 250-08 approved design ensures safety standards are met while its 90~305 VAC / 127~431 VDC input voltage and 0.8A/115VAC 0.4A/230VAC
0.32A/277VAC input ac current provide reliable performance with an efficiency of
89%. Get yours today!

Suitable for Led lighting and moving sign applications (moving Led display). Suitable for dry/damp/wet locations.
Protections: Short circuit/Over current/Over voltage/Over temperature.
Built-in active PFC function.
Built-in three in one dimming function (1~10 VDC or PWM signal or resistance).
Cooling by free air convection.
Fully isolated plastic case.
IP67 rated - suitable for outdoor use.
Class II power unit, no FG (floating ground).
Five-year warranty.

• Universal AC input / Full range (up to
  305 VAC)
• Cooling by free air convection
• Built-in active PFC function
• Built-in three in one dimming function (1~10 VDC or PWM signal or resistance)

• Input voltage: 90~305 VAC / 127~431 VDC
• Input ac current: 0.8 A / 115 VAC, 0.4 A / 230 VAC,
  0.32 A / 277 VAC
• Output: 24V /2.5A/60W
• Efficiency:89%

This LED driver LPF 60D is the perfect choice for your Led lighting and moving sign applications. It features universal AC input, active PFC function, three in one dimming function, cooling by free air convection, fully isolated plastic case with IP67 rating and five years warranty.
UL8750/CSA C22.2 No.250-08 approved design ensures safety standards are met while its wide input voltage range of
90~305V AC or
127~431V DC provides reliable performance with an efficiency of up to
89%. Get yours today!

Download LPF-60D-SPEC.pdf
