LED driver LPF 25 12 12V 25W IP67

This LED driver LPF 25 12 12V 25W IP67 is perfect for your Led lighting and moving sign applications. It offers universal AC input, full range up to 305 VAC, active PFC function, cooling by free air convection and a fully isolated plastic case with IP67 rating. Enjoy 5 years warranty and safety standards UL8750, CSA C22.2 No. 250.0-08, EN61347-1 & more! Input voltage: 90~305 VAC/127~431VDC; Output: 12V/2.1A/25W; Efficiency: 84%; Dimensions: 148×40×32mm; Weight:0.36kg

This LED driver LPF 25 is designed specifically for Led lighting and moving sign applications (moving Led display). It provides reliable power supply with its universal AC input / Full range feature that supports voltages up to an impressive maximum of 305 VAC. With built-in active PFC function and cooling by free air convection, this LED driver ensures efficient performance while maintaining optimal temperature levels.

The advantages of using the LED driver LPF 25 are numerous:

• Suitable for dry/damp/wet locations - This makes it versatile in terms of installation options.
• Fully isolated plastic case - Ensures safety during operation.
• IP67 rating - Provides protection against dust ingress and water immersion up to a certain depth.
• No FG (Class II power unit) - Eliminates the need for grounding connection.
• 5 years warranty - Offers peace of mind knowing that the product is backed by a reliable warranty.

The LED driver LPF 25 comes with the following features:

• Short circuit protection - Safeguards against potential short circuits.
• Over current protection - Prevents excessive current flow and potential damage to connected devices.
• Over voltage protection - Protects against voltage spikes that could harm the LED lighting system.
• Over temperature protection - Ensures safe operation even in high-temperature environments.

The LED driver LPF 25 is specifically designed for Led lighting and moving sign applications. It provides reliable power supply for various types of Led lighting systems, including moving Led displays. Whether you need to illuminate indoor spaces or create eye-catching outdoor signage, this LED driver offers the necessary power and performance to meet your requirements.

• Input voltage: 90~305 VAC / 127~431 VDC
• Input ac current:
    0.4 A / 115 VAC
    0.25 A / 230 VAC
    0.2 A / 277 VAC

Please note: The technical data provided above are subject to change without prior notice as part of our continuous improvement process.
For detailed specifications, please refer to the product datasheet available on our website or contact our sales team directly.

Download LPF-25-SPEC-2
