059483 | Manufacturer: Vossloh Schwabe | EAN: 4050732059483 | MPN: 188922
ELXc 235 221 2x14W 2x21W 2x35W T5 electronic ballasts for lamp
Product is out of production!
Product tags Product tags
ELXc 235.221 2x14W 2x21W 2x28W 2x35W T5: High-performance electronic ballast for T5 fluorescent lamps. Achieve optimal lighting with this RFI-suppressed, IP20 protected ballast suitable for protection class I luminaires. With a power factor of ≥0.95 and a wide operating voltage range, it ensures reliable performance in lighting systems with high switching frequency. Perfectly designed for T5 lamps (G5) with an output of 2 × 14W, 2 × 21W, 2 ×28W, or 2 ×35W. Ideal for various applications with an ambient temperature range from -15°C to +55°C.
More info
Vossloh Schwabe ELXc 235 221 2x14W 2x21W 2x35W T5 electronic ballasts for lamp Ballast. Illuminate your space with the ELXc 235.221 electronic ballast for T5 lamps. Efficiently power up to four bulbs, saving energy and brightening any room effortlessly.
Electronic built-in ballasts
Casing: metal
Power factor: ≥ 0.95
DC voltage: for operation: 176 - 264 V, for ignition: 198 - 264 V (ELXc 149.858: DC voltage cannot be reduced to 176 V)
Push-in terminals: 0.5 - 1 mm²
For the automatic luminaire wiring: IDC terminals for leads H05 V-U 0.5
RFI-suppressed
For luminaires of protection class I
Degree of protection: IP20
For Lighting systems with high switching frequency ( > 5/day)
EOL shut down approved acc. to EN 61347
Lamp type: T5
Output [W]: 2 × 14, 2 × 21, 2 × 28, 2 × 35 for T5 lamps (G5)
Lamp number: 2
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –15 to 55
| Explanation Dimmable | no |
| Explanation Voltage - (V) | 220 |
| Explanation Protection mark - (IPXX) | 20 |
| Explanation Factory packed - (pieces) | 10 |
