049323 | Manufacturer: Vossloh Schwabe | EAN: 4050732049323 | MPN: 188700
ELXc 142 872 1x18 42W 2x18 26W electronic ballasts
Product is out of production!
Product tags Product tags
ELXc 142.872 is a powerful electronic ballast designed for compact fluorescent lamps. With its heat-resistant polyamide casing and high power factor of >0.96, this ballast ensures efficient and reliable operation. It features push-in terminals for easy installation and is RFI-suppressed for minimal interference. Suitable for luminaires of protection class I, it has an IP20 degree of protection and can be mounted laterally or on the base using fixing brackets. Approved for EOL shut down according to EN 61347 Test 2, it supports various lamp types with different output wattages, making it versatile for different lighting systems.
More info
Vossloh Schwabe ELXc 142 872 1x18 42W 2x18 26W electronic ballasts Ballast. Illuminate your space with the ELXc 142.872 electronic ballast, delivering efficient lighting for 1x18 42W and 2x18 26W bulbs. Upgrade illumination today
Electronic built-in ballasts
Casing: heat-resistant polyamide
DC voltage: for operation: 176 - 264 V, for ignition: 198 - 264 V (ELXc 242.837: DC voltage cannot be reduced to 176 V)
Power factor: > 0.96
Push-in terminals: 0.5 - 1.5 mm²
RFI-suppressed
For luminaires of protection class I
Degree of protection: IP20
Fixing brackets for screws M4 for lateral or base mounting
For lighting systems with high switching frequency ( > 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-F/-L, TC-DEL/-TEL, TC-DD, T-R5
Output [W]: 18, 2 × 18, 24, 2 × 24, 36, 40 for compact fluorescent lamps TC-F/-L (2G10/2G11)
Output [W]: 22, 40 for compact fluorescent lamps T-R5 (2GX13)
Output [W]: 26, 2 × 26, 32, 42 for compact fluorescent lamps TC-DEL/-TEL (G24q-3/GX24q-3)
Output [W]: 38 for compact fluorescent lamps TC-DD (GR10q)
Lamp number: 1 - 2
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –20…50
| Explanation Dimmable | no |
| Explanation Voltage - (V) | 220 |
| Explanation Protection mark - (IPXX) | 20 |
| Explanation Factory packed - (pieces) | 10 |
