LED driver LPF 16D 24 24V 16W IP30 brighten your home with mean well

This LED driver LPF 16D 24 24V 16W IP30 is the perfect choice for your lighting needs. With its advanced technology and superior performance, you can be sure o

This LED driver LPF 16D 24 24V 16W IP30 is perfect for your Led lighting and moving sign applications. It features universal AC input, active PFC function, 3 in 1 dimming function, cooling by free air convection, fully isolated plastic case and IP30 protection. UL8750/CSA C22.2 No. 250-08 approved with 5 years warranty - get the best quality at an unbeatable price!

Suitable for Led lighting and moving sign applications (moving Led display).

Suitable for dry/ damp/ wet locations.Universal AC input / Full range (up to 305 VAC).Protections: Short circuit/ Over current/ Over voltage/ Over temperature.Built-in active PFC function.Built-in 3 in 1 dimming function (1~10 VDC or PWM signal or resistance).Cooling by free air convection.Fully isolated plastic case.IP30.Class II power unit, no FG.

• Input voltage: Universal AC input / Full range (up to 305 VAC)
• Input ac current:
• 0.4 A /115 VAC
• 0.25 A /230 VAC
• 0.2 A /277 VAC
• Built-in active PFC function
• Built-in three in one dimming function(1~10Vdc or PWM signal or resistance)
• Cooling by free air convection
• Fully isolated plastic case
• IP30 design for indoor or outdoor installations

This LED driver LPF 16D 24 24V 16W IP30 is suitable for Led lighting and moving sign applications (moving Led display).

• Suitable for dry/ damp/ wet locations.
• Universal AC input / Full range (up to 305 VAC)
• Protections: Short circuit/ Over current/ Over voltage/ Over temperature
• Built-in active PFC function
• Built-in three in one dimming function(1~10Vdc or PWM signal or resistance)
• Cooling by free air convection
Main Features:

- Input Voltage: Universal AC input / Full range (up to 305 VAC)
- Built-in active PFC function
- Cooling by free air convection
- Fully isolated plastic case
- IP30 design for indoor or outdoor installations.

**Note**: Please refer to the product datasheet for detailed technical specifications.


Please indicate any advice here.

Please indicate any warnings here.

This LED driver LPF 16D 24 is perfect for your Led lighting and moving sign applications. It features universal AC input, active PFC function, cooling by free air convection, fully isolated plastic case and IP30 protection. UL8750/CSA C22.2 No. 250-08 approved with 5 years warranty - get the best quality at an unbeatable price!

Download LPF-16D-SPEC.pdf
