LED driver LPF 16 24 24V 16W IP30 brighten your home with mean well

This LED driver LPF 16 24 24V 16W IP30 is the perfect choice for your lighting needs. With its advanced technology and superior performance, you can be sure of

This LED driver LPF 16 24 24V 16W IP30 is the perfect choice for your Led lighting and moving sign applications. It features universal AC input, active PFC function, cooling by free air convection, fully isolated plastic case with IP30 rating and 5 years warranty. With UL8750, CSA C22.2 No. 250.0-08 certifications and 90~305 VAC / 127~431 VDC input voltage range it ensures safety and reliability in any environment.

Suitable for Led lighting and moving sign applications (moving Led display). Suitable for dry/ damp/ wet locations. Universal AC input / Full range (up to 305 VAC). Protections: Short circuit/ Over current/ Over voltage/ Over temperature. Built-in active PFC function. Cooling by free air convection. Fully isolated plastic case with IP30 rating.

- Universal AC input allows usage in various environments.- Active PFC function improves energy efficiency.- Cooling by free air convection eliminates the need for additional cooling systems.- Fully isolated plastic case provides protection against electrical shocks.- IP30 rating ensures resistance to dust particles larger than two millimeters.

• Suitable for Led lighting and moving sign applications (moving Led display)
• Suitable for dry/damp/wet locations
• Universal AC input / Full range (up to 305 VAC)
• Protections: Short circuit/Over current/Over voltage/Over temperature
• Built-in active PFC function
• Cooling by free air convection
• Fully isolated plastic case
• IP30 rating
• Class II power unit, no FG
• 5 years warranty
• SAFETY STANDARDS: UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13 independent, EN62384,J61347-1, J61347-2-13 approved, IP67 (optional); Design refer to UL60950-1,TUV EN60950-

This LED driver is suitable for various Led lighting and moving sign applications such as moving Led displays.

• Input voltage: 90~305 VAC / 127~431 VDC
• Input ac current: 0.4 A / 115 VAC; 0.25 A / 230 VAC; 0.2 A /277 VAC
• Output:24V/0.67A/16W
• Efficiency :86%
• Dimensions :148 ×40×32mm
• Weight :0 .21kg

Please note that the technical data provided above are subject to change without prior notice.

Please ensure that the input voltage range of your LED lighting or moving sign application falls within the specified range of this LED driver to avoid any compatibility issues.

:Please do not attempt to modify or disassemble this product as it may result in electric shock or damage to the product. Always consult a qualified technician for any repairs or modifications.

Get this LED driver LPF 16 24 24V 16W IP30 now and enjoy reliable and efficient power supply for your Led lighting and moving sign applications!

Download LPF-16-SPEC.pdf
