Vossloh Schwabe ELXs 116.900 1x4 16W TC SEL TC dEL TC dD T5 T8

Electronic built-in ballast
Casing: heat-resistant polyamide
Power factor: approx. 0.6 (depending on the lamp output)
DC voltage operation: 198–264V
Push-in terminals with push-button: 0.5–1.5mm²
RFI-suppressed
For luminaires of protection class I and II
Degree of protection: IP20
Fixing slots for screws M4
For lighting systems with high switching frequency (> 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-SEL, TC-DEL, TC-DD, T5, T8
Output [W]: 5, 7, 9, 11 for compact fluorescent lamps TC-SEL (2G7)
Output [W]: 10 for compact fluorescent lamps TC-DEL (G24q-1)
Output [W]: 10, 16 for compact fluorescent lamps TC-DD (GR10q)
Output [W]: 4, 6, 8, 13 for T5 lamps (G5)
Output [W]: 16 for T8 lamps (G13)
Lamp number: 1
Voltage AC [V]: 220-240V
Frequency [Hz]: 50-60Hz
Ambient temperature ( °C) -15 to 55
