Predstikalne naprave, elektronske

Osram QT eco 1x18 21/220V S

794907 | Proizvajalec: Osram | EAN: 4050300794907 | MPN: QT-ECO-1-18-21-S

QUICKTRONIC ECONOMIC elektronska predstikalna naprava za fluorescenčne sijalke premera 7 mm in za kompaktne fluorescenčne sijalke.


15,75 €z DDV
12,91 €brez DDV

Cena za 1 kos.
Stanje: Nov izdelek
Tovarniško pakiranje - kosov (kos): 50

-+

Z nakupom tega izdelka lahko zberete do 2 točk zvestobe. Vaša košarica bo dobila skupaj 2 točke, ki se jih lahko zamenja za kupon v vrednosti 0,20 €.

Podrobnosti

Nominal voltage 220…240V
Mains frequency 50Hz
DC voltage 176…254V
Operating frequency 35…45 kHz
Max. no. of ECGs on circuit breaker 10A 36
Max. no. of ECGs on circuit breaker 16A 59

Starting time 1.5 s

Length 80 mm
Width 40 mm
Height 22 mm
Mounting hole spacing, length 72.0…75 mm

Ambient temperature range -15…+50 °C

Dimmable No
Suitable for fixtures with prot. class I / II
End of lamp life safety shutdown EOL T.2

Approval marks – approval VDE
EEI – Energy Label A3
Standards acc. to EN 61347-2-3/acc. to EN 55015: 2006 + A1: 2007/acc. to EN 61000-3-2/acc. to EN 61547

Product benefits
-Compact housing
-Automatic restart after lamp replacement

Areas of application
-Public buildings

Product features
-Supply voltage: 220…240V
-Line voltage: 198…264V
-Line frequency: 50Hz | 60Hz
-Energy Efficiency Index EEI: A2
-Automatic shutdown of defective lamps and at end of life (EoL)

Tehnični podatki

Tehnični podatki: Predstikalne naprave, elektronske QT eco 1x18 21/220V S

Možnost zatemnitveNe
Napetost - Volt (V)220
Tovarniško pakiranje - kosov (kos)50
Prenosi

Prenosi: Predstikalne naprave, elektronske, QT eco 1x18 21/220V S

Varnostna navodila

Komentarji

Skupna ocena: 5,00 / 5

Temelji na 3 komentarjev


Napiši komentar


5 - Rating

En remplacement d'un ballast "no name", installation facile et fonctionnement sans surprise.

,
5 - Rating

These pieces are so difficult to find in France, there is an excellent selection at Svetila, competitive pricing and good service thank you.

,
5 - Rating

Works well, and so much cheaper than buying a similar item locally. Thank you.

,
